무계목 스텐레스 강관 (Seamless Pipe & Tube)
-
용 도
제지공업, 석유화학공업, 비료공업, 식품제조설비, 식음료배관, 폐수처리장비, 자동차 및 항공기 부품. 발전설비 등
-
규격표(KS,ASTM 기준)
|
호칭경 |
외경 |
SCHDULE |
||||||||||||||
|
SCH 5S |
SCH10S |
SCH20S |
SCH40 |
SCH80 |
SCH120 |
SCH160 |
||||||||||
|
A |
B |
KS (JIS) |
ASTM |
KS |
ASTM |
KS |
ASTM |
KS |
KS |
ASTM |
KS |
ASTM |
KS |
ASTM |
KS |
ASTM |
|
6 |
1/8 |
10.5 |
10.29 |
1.0 |
- |
1.2 |
1.24 |
1.5 |
1.7 |
1.73 |
2.4 |
2.41 |
|
|
|
|
|
8 |
1/4 |
13.8 |
13.72 |
1.2 |
- |
1.65 |
1.65 |
2.0 |
2.2 |
2.24 |
3.0 |
3.02 |
|
|
|
|
|
10 |
3/8 |
17.3 |
17.15 |
1.2 |
- |
1.65 |
1.65 |
2.0 |
2.3 |
2.31 |
3.2 |
3.20 |
|
|
|
|
|
15 |
1/2 |
21.7 |
21.34 |
1.65 |
1.65 |
2.1 |
2.11 |
2.5 |
2.8 |
2.77 |
3.7 |
3.73 |
|
|
4.7 |
4.78 |
|
20 |
3/4 |
27.2 |
26.67 |
1.65 |
1.65 |
2.1 |
2.11 |
2.5 |
2.9 |
2.87 |
3.9 |
3.91 |
|
|
5.5 |
5.56 |
|
25 |
1 |
34.0 |
33.40 |
1.65 |
1.65 |
2.8 |
2.77 |
3.0 |
3.4 |
3.38 |
4.5 |
4.55 |
|
|
6.4 |
6.35 |
|
32 |
1 1/4 |
42.7 |
42.16 |
1.65 |
1.65 |
2.8 |
2.77 |
3.0 |
3.6 |
3.56 |
4.9 |
4.85 |
|
|
6.4 |
6.35 |
|
40 |
1 1/2 |
48.6 |
48.26 |
1.65 |
1.65 |
2.8 |
2.77 |
3.0 |
3.7 |
3.68 |
5.1 |
5.08 |
|
|
7.1 |
7.14 |
|
50 |
2 |
60.5 |
60.33 |
1.65 |
1.65 |
2.8 |
2.77 |
3.0 |
3.9 |
3.91 |
5.5 |
5.54 |
|
|
8.7 |
8.73 |
|
65 |
2 1/2 |
76.3 |
73.03 |
2.1 |
2.11 |
3.0 |
3.05 |
3.5 |
5.2 |
5.16 |
7.0 |
7.01 |
|
|
9.5 |
9.53 |
|
80 |
3 |
89.1 |
88.90 |
2.1 |
2.11 |
3.0 |
3.05 |
4.0 |
5.5 |
5.49 |
7.6 |
7.62 |
|
|
11.1 |
11.13 |
|
90 |
3 1/2 |
101.6 |
101.60 |
2.1 |
2.11 |
3.0 |
3.05 |
4.0 |
5.7 |
5.74 |
8.1 |
8.08 |
|
|
12.7 |
12.70 |
|
100 |
4 |
114.3 |
114.30 |
2.1 |
2.11 |
3.0 |
3.05 |
4.0 |
6.0 |
6.02 |
8.6 |
8.56 |
11.1 |
|
13.5 |
13.49 |
|
125 |
5 |
139.8 |
141.30 |
2.8 |
2.77 |
3.4 |
3.40 |
5.0 |
6.6 |
6.55 |
9.5 |
9.52 |
12.7 |
|
15.9 |
15.58 |
|
150 |
6 |
165.2 |
168.28 |
2.8 |
2.77 |
3.4 |
3.40 |
5.0 |
7.1 |
7.11 |
11.0 |
10.97 |
14.3 |
|
18.2 |
18.26 |
|
200 |
8 |
216.3 |
219.08 |
2.8 |
2.77 |
4.0 |
3.76 |
6.5 |
8.2 |
8.18 |
12.7 |
12.7 |
18.2 |
|
23.0 |
23.01 |
|
250 |
10 |
267.4 |
273.05 |
3.4 |
3.40 |
4.0 |
4.19 |
6.5 |
9.3 |
9.27 |
15.1 |
12.7 |
21.4 |
|
28.6 |
28.58 |
|
300 |
12 |
318.5 |
323.85 |
4.0 |
3.96 |
4.5 |
4.57 |
6.5 |
10.3 |
9.52 |
17.4 |
12.7 |
25.4 |
|
33.3 |
33.32 |
|
350 |
14 |
355.6 |
4.0 |
3.96 |
5.0 |
4.78 |
8.0 |
11.1 |
- |
19.0 |
- |
27.8 |
|
35.7 |
|
|
|
400 |
16 |
406.4 |
4.5 |
4.19 |
5.0 |
4.78 |
8.0 |
12.7 |
- |
21.4 |
- |
30.9 |
|
40.5 |
|
|
|
450 |
18 |
457.2 |
4.5 |
4.19 |
5.0 |
4.78 |
8.0 |
14.3 |
|
23.8 |
|
34.9 |
|
45.2 |
|
|
|
500 |
20 |
508.0 |
5.0 |
4.78 |
5.5 |
5.54 |
9.5 |
15.1 |
|
26.2 |
|
38.1 |
|
50.0 |
|
|
|
550 |
22 |
558.8 |
5.0 |
4.78 |
5.5 |
5.54 |
9.5 |
15.9 |
|
28.6 |
|
41.3 |
|
54.0 |
|
|
|
600 |
24 |
609.6 |
5.5 |
5.54 |
6.5 |
6.35 |
9.5 |
17.5 |
|
31.0 |
|
46.0 |
|
59.5 |
|
|
|
650 |
26 |
660.4 |
5.5 |
- |
8.0 |
- |
12.7 |
17.5 |
|
34.0 |
|
49.1 |
|
64.2 |
|
|
|
700 |
28 |
711.2 |
5.5 |
- |
8.0 |
- |
12.7 |
17.5 |
|
|
|
|
|
|
|
|
|
750 |
30 |
762.0 |
6.5 |
6.35 |
8.0 |
- |
12.7 |
17.5 |
|
|
|
|
|
|
|
|
|
800 |
32 |
812.8 |
- |
- |
8.0 |
- |
12.7 |
17.5 |
|
|
|
|
|
|
|
|
|
850 |
34 |
863.6 |
- |
- |
8.0 |
- |
12.7 |
17.5 |
|
|
|
|
|
|
|
|
|
900 |
36 |
914.4 |
- |
- |
8.0 |
- |
12.7 |
19.1 |
|
|
|
|
|
|
|
|
|
1000 |
40 |
1016.0 |
- |
- |
9.5 |
- |
14.3 |
26.2 |
|
|
|
|
|
|
|
|
